VMR2-S SNOWPLOW - "V" plow

lame sgombraneve vomere vmr2 thor lame sgombraneve snow service srl 01

The VMR2-S V-plow in designed for hard winter conditions and it fits trucks with GVW>100 quintals, agricultural tractors with power over 90 hp and weight > 45 quintals and 90 hp backhoe loaders or wheel loaders. Completely made of high-strength steel and equipped with quick hitch plate for easy attachment complying with the standards DIN 76060/A.

Central body made of high-strength steel on which are jointed the side blades by means of N. 6 Hardox hinges. Incidence (longitudinal pitch angle) adjustable by means of a mechanical - manual system (third upper point) or, on request, by an automatic hydraulic system.

The VMR2-S V-plow is equipped with end-stroke mechanical stops in positions of maximum inclination (to protect the hydraulic cylinders for the blades handling). Nitrogen accumulator to reduce the side shock loading installed on the hydraulic circuit of the cylinders for the blade’s movements, combined with overpressure valves and with bottom rubber splashguards on which are fitted the cutting edges.

Mechanical coupling system of the DIN plate with the central body, which allows a transverse pitch angle of + 5°, with automatic horizontal locking of the equipment lifted from the ground, in motion. Painted with special anti-rust treatment and final paint RAL 2011 (orange). R2 pipes with fittings and unified quick couplings. The V-plow modes: “V” mode (angle 90°), blade inclined completely to the right or left (angle 45°) and reverse wedge (scoop mode) with internal angle of 40°, in addition to all intermediate positions.

Mode of operation of the VMR2-S

Hydraulically driven, through hydraulic double-effect cylinders for the movement of every single blade and for lifting/lowering procedures.

Power supply

24 Volt electro- hydraulic power unit installed, on request (optional), on the snowplow. As an alternative option, a special hydraulic system installed on the vehicle (3 double-effect distributors required, one with a floating position).

Handling settings

Control of the plow by means of the electronic push-button panel, with cable of appropriate length, and of the electro-hydraulic unit. As an alternative option, commands already present on the vehicle if equipped with a special hydraulic system (ex. agricultural tractor).


For further information on the
VMR2-S -“V” plow and for a custom-made offer do not hesitate to directly contact us or fill the "Contact" form on this page!

CodeModelWeight (kg)Weight with control unit (kg)Height at the tip (mm)Wingtip height (mm)Encumbrance: spoon mode - A (mt) Encumbrance: blade mode - B (mt)  Encumbrance: "V" mode - C (mt) MAX working encumbrance - D (mt)
5030990 VMR2-S MT. 2,40 800 860 890 1330 2,40 2,54 2,45 2,98
5030420 VMR2-S MT. 2,60 1000 1060 1040 1360 2,60 2,74 2,65 3,67
5030430 VMR2-S MT. 2,90 1200 1260 1040 1400 2,9 3,04 2,95 3,60
